NVIDIA Jetson Orin NX/Nano

  Jetson Orin NX/Nano 2CH GMSL3 camera adapter board Overview  SG2A-G3-M4L adapter board, which allows up to 2 cameras to be connected to the NVIDIA JetsonOrin Nano/NX module, is fully compatible with the NVIDIA Jetson Orin Nano/NX Development Kit. As thereare many different types of GMSL cameras available, the adapter board can be adaptively operated atdifferent frequencies i.e. it is compatible with both GMSL2 and GMSL3 protocol interfaces through softftwareconfiguration. The GMSL camera is powered by PoC (Power over Coax), so all data, control signals and powerare sent over a 50 Ohm coaxial cable, making the camera's cable routing flexible and easy to install inautomotive applications. Adapter plate function Compatible with offfficial kits Support for NVIDIA Jetson Orin Nano/NX Development Kit Compatible with different versions of NVIDIA JetPack SDK Jetpack 5.1, L4T r35.2.1 and above Supports up to 2 GMSL cameras Support for synchronous triggering Support for external trigger signals for camera synchronisation Cameras can transmit up to 14 metres By using the GMSL protocol for cameras, you can support stable and reliable transmission of cameras over long distances, with a maximum distance support of 14 metres. Instructions for using the adapter plate The SG2A-G3-M4L is an adapter board for use with the NVIDIA Jetson Orin Nano/NX kit. The driverpackage was developed on a specific Jetson Linux version and you need to make sure the Jetson Linuxversion matches before installing the driver. r. If it does not match, you need to re-flash the system, otherwisethe system will not boot after installing the driver. r. NVIDIA Jetson Orin Nano/NX supports two types offlushing methods, using SDK Manager and via the Flash.sh script. Here is how to use the Flash.sh script. Preparation required SG2A-G3-M4L adapter board to NVIDIA Jetson Xavier/Orin Nano/NX kit Computer with Ubuntu 18.04/20.04s 1 USB TYPE-C data cable 1pc

  Jetson Orin NX/Nano 2CH GMSL3 camera adapter board Overview  SG2A-G3-M4L adapter board, which allows up to 2 cameras to be connected to the NVIDIA JetsonOrin Nano/NX module, is fully compatible with the NVIDIA Jetson Orin Nano/NX Development Kit. As thereare many different types of GMSL cameras available, the adapter board can be adaptively operated atdifferent frequencies i.e. it is compatible with both GMSL2 and GMSL3 protocol interfaces through softftwareconfiguration. The GMSL camera is powered by PoC (Power over Coax), so all data, control signals and powerare sent over a 50 Ohm coaxial cable, making the camera's cable routing flexible and easy to install inautomotive applications. Adapter plate function Compatible with offfficial kits Support for NVIDIA Jetson Orin Nano/NX Development Kit Compatible with different versions of NVIDIA JetPack SDK Jetpack 5.1, L4T r35.2.1 and above Supports up to 2 GMSL cameras Support for synchronous triggering Support for external trigger signals for camera synchronisation Cameras can transmit up to 14 metres By using the GMSL protocol for cameras, you can support stable and reliable transmission of cameras over long distances, with a maximum distance support of 14 metres. Instructions for using the adapter plate The SG2A-G3-M4L is an adapter board for use with the NVIDIA Jetson Orin Nano/NX kit. The driverpackage was developed on a specific Jetson Linux version and you need to make sure the Jetson Linuxversion matches before installing the driver. r. If it does not match, you need to re-flash the system, otherwisethe system will not boot after installing the driver. r. NVIDIA Jetson Orin Nano/NX supports two types offlushing methods, using SDK Manager and via the Flash.sh script. Here is how to use the Flash.sh script. Preparation required SG2A-G3-M4L adapter board to NVIDIA Jetson Xavier/Orin Nano/NX kit Computer with Ubuntu 18.04/20.04s 1 USB TYPE-C data cable 1pc

  Jetson Orin NX/Nano 2CH GMSL2 camera adapter board Overview  SG2A-G2-M4L-F adapter board, which allows up to 2 cameras to be connected to the NVIDIAJetson Orin Nano/NX module, is fully compatible with the NVIDIA Jetson Orin Nano/NX Development Kit. Asthere are many difffferent types of GMSL cameras available, the adapter board can be adaptively operated atdifferent frequencies i.e. it is compatible with both GMSL1 and GMSL2 protocol interfaces through softftwareconfiguration. The GMSL camera is powered by PoC (Power over Coax), so all data, control signals and powerare sent over a 50 Ohm coaxial cable, making the camera's cable routing flexible and easy to install inautomotive applications.  Adapter plate function Compatible with offfficial kits Support for NVIDIA Jetson Orin Nano/NX Development Kit Compatible with different versions of NVIDIA JetPack SDK Jetpack 5.1, L4T r35.2.1 and above Supports up to 2 GMSL cameras Support for synchronous triggering Support for external trigger signals for camera synchronisation Cameras can transmit up to 15 metres By using the GMSL protocol for cameras, you can support stable and reliable transmission of cameras over long distances, with a maximum distance support of 15 metres. Instructions for using the adapter plate The SG2A-G2-M4L-F is an adapter board for use with the NVIDIA Jetson Xavier/Orin Nano/NX kit. Thedriver package was developed on a specific Jetson Linux version and you need to make sure the Jetson Linuxversion matches before installing the driver. r. If it does not match, you need to re-flash the system, otherwisethe system will not boot after installing the driver. r. NVIDIA Jetson Xavier/Orin Nano/NX supports two typesof flushing methods, using SDK Manager and via the Flash.sh script. Here is how to use the Flash.sh script. Preparation required SG2A-G2-M4L-F adapter board to NVIDIA Jetson Xavier/Orin Nano/NX kit Computer with Ubuntu 18.04/20.04s 1 USB TYPE-C data cable 1pc

  Jetson Orin NX/Nano 2CH GMSL2 camera adapter board Overview  SG2A-G2-M4L-F adapter board, which allows up to 2 cameras to be connected to the NVIDIAJetson Orin Nano/NX module, is fully compatible with the NVIDIA Jetson Orin Nano/NX Development Kit. Asthere are many difffferent types of GMSL cameras available, the adapter board can be adaptively operated atdifferent frequencies i.e. it is compatible with both GMSL1 and GMSL2 protocol interfaces through softftwareconfiguration. The GMSL camera is powered by PoC (Power over Coax), so all data, control signals and powerare sent over a 50 Ohm coaxial cable, making the camera's cable routing flexible and easy to install inautomotive applications.  Adapter plate function Compatible with offfficial kits Support for NVIDIA Jetson Orin Nano/NX Development Kit Compatible with different versions of NVIDIA JetPack SDK Jetpack 5.1, L4T r35.2.1 and above Supports up to 2 GMSL cameras Support for synchronous triggering Support for external trigger signals for camera synchronisation Cameras can transmit up to 15 metres By using the GMSL protocol for cameras, you can support stable and reliable transmission of cameras over long distances, with a maximum distance support of 15 metres. Instructions for using the adapter plate The SG2A-G2-M4L-F is an adapter board for use with the NVIDIA Jetson Xavier/Orin Nano/NX kit. Thedriver package was developed on a specific Jetson Linux version and you need to make sure the Jetson Linuxversion matches before installing the driver. r. If it does not match, you need to re-flash the system, otherwisethe system will not boot after installing the driver. r. NVIDIA Jetson Xavier/Orin Nano/NX supports two typesof flushing methods, using SDK Manager and via the Flash.sh script. Here is how to use the Flash.sh script. Preparation required SG2A-G2-M4L-F adapter board to NVIDIA Jetson Xavier/Orin Nano/NX kit Computer with Ubuntu 18.04/20.04s 1 USB TYPE-C data cable 1pc

  6CH GMSL2 Camera Developer Kit for NVIDIA Jetson Orin Nano/NX Overview  SG6C-ORNX-G2-F is a computing platform carrier board designed for NVIDIA Jetson Xavier/Orin NX series modules, and is also compatible with TX2-NX and Nano SOM core modules. PCIe expandable 4G, M.2 Key-Baccess to 5G modules, 2-way CAN bus, 2-way USB3.0 compatible with 2.0, etc. With long MTBF stable operation capability, it is widely used in low-speed automatic driving controller,logistics, security, transportation and other industries, and the end product form is rich for application in robots, drones, unmanned delivery vehicles, unmanned ships, intelligent law enforcement equipment, etc. Adapter plate function Support for NVIDIA Jetson AGX Orin/Xavier Development Kit Support for NVIDIA Jetson Xavier/Orin NX (compatible with TX2-NX/Nano) Supports M.2 KEY M 2280 (PCIex4 NVMe SSD or Compute Stick) Supports 6 GMSL cameras (GMSL1 and GMSL2 compatible) Supports M.2 KeyB extension interface for access to 5G modules Supports mini-PCIe expansion interface for access to 4G modules Supports dual Gigabit RJ45 network interfaces Dual-band WIFI support and optional GPS support Supports a wide range of interfaces (e.g. USB/Serial/CAN/GPIO, etc.) Compatible with installation of different versions of NVIDIA JetPack SDK Carrier board operating instructions Instructions for using the adapter plate The SG6C-ORNX-G2-F carrier board is used with NVIDIA Jetson Xavier/Orin NX and other core boards. The driver package is developed on a specific Jetson Linux version and you need to make sure the Jetson Linux version matches before installing the driver. If it does not match,you need to re-flash the system, otherwise the system will not boot after installing the driver. NVIDIA Jetson Xavier/Orin NX supports two types of flushing methods, using SDK Manager and via the Flash.sh script. Preparation required SG6C-ORNX-G2-F carrier board with NVIDIA Jetson Xavier/Orin NX module and SSD Computer with Ubuntu 18.04/20.04 USB TYPE-C data cable 1pc

  Jetson Orin Nano/NX 6CH GMSL2 Camera Carrier Board Overview  SG6C-ORNX-G2-F is a computing platform carrier board designed for NVIDIA Jetson Xavier/Orin NX series modules, and is also compatible with TX2-NX and Nano SOM core modules. PCIe expandable 4G, M.2 Key-Baccess to 5G modules, 2-way CAN bus, 2-way USB3.0 compatible with 2.0, etc. With long MTBF stable operation capability, it is widely used in low-speed automatic driving controller,logistics, security, transportation and other industries, and the end product form is rich for application in robots, drones, unmanned delivery vehicles, unmanned ships, intelligent law enforcement equipment, etc. Adapter plate function Support for NVIDIA Jetson AGX Orin/Xavier Development Kit Support for NVIDIA Jetson Xavier/Orin NX (compatible with TX2-NX/Nano) Supports M.2 KEY M 2280 (PCIex4 NVMe SSD or Compute Stick) Supports 6 GMSL cameras (GMSL1 and GMSL2 compatible) Supports M.2 KeyB extension interface for access to 5G modules Supports mini-PCIe expansion interface for access to 4G modules Supports dual Gigabit RJ45 network interfaces Dual-band WIFI support and optional GPS support Supports a wide range of interfaces (e.g. USB/Serial/CAN/GPIO, etc.) Compatible with installation of different versions of NVIDIA JetPack SDK Carrier board operating instructions Instructions for using the adapter plate The SG6C-ORNX-G2-F carrier board is used with NVIDIA Jetson Xavier/Orin NX and other core boards. The driver package is developed on a specific Jetson Linux version and you need to make sure the Jetson Linux version matches before installing the driver. If it does not match,you need to re-flash the system, otherwise the system will not boot after installing the driver. NVIDIA Jetson Xavier/Orin NX supports two types of flushing methods, using SDK Manager and via the Flash.sh script. Preparation required SG6C-ORNX-G2-F carrier board with NVIDIA Jetson Xavier/Orin NX module and SSD Computer with Ubuntu 18.04/20.04 USB TYPE-C data cable 1pc
